| Part Number | ESXWHB31-S50C | Distance | 500m |
| Form Factor | OSFP | Connector | 2x MPO-12(APC) |
| Wavelength | 1310nm | Transmitter | DFB |
| Receiver | PIN | Media | Single-Mode Fiber?(SMF) |
| Power Consumption | <16W | Protocol | 800G Base Ethernet |
| Case Temperature(℃) | C: 0℃ to +70℃ |
Product Features
Data rate up to 850Gbps (4xPAM1062.5GBd).
Supports High-speed I/O interface (800GAUI-8).
Maximum link length of 500m over SMF (single-mode fiber).
Supports the following applications:
800GBASE-DR8
400GBASE-DR4
2x400GBASE-DR4
4x200GBASE-DR2
Compliance with OSFP MSA Rev5.0.
Optical connector: MPO-16 (APC).
Power Consumption: < 15W.
Management interface: CMIS 5.2.
+3.3V single power supply.
Product Highlights
A cutting-edge solution for high-speed data transmission over Single Mode Fiber (SMF). Designed for high-performance networking, this OSFP Infiniband Transceiver supports 800G speeds, ensuring seamless connectivity and ultra-low latency across data centers and enterprise networks. With its 1310nm wavelength and a reach of up to 500 meters, it offers optimal performance for long-distance data transmission. Whether you need an OSFP Transceiver for demanding applications or an OSFP DR8 module for efficient, high-capacity data transfer, our product provides unmatched reliability and scalability for next-generation optical networks.
Cloud and Data Storage Solutions
The 800G OSFP 1310nm DR8 500m module is a crucial component for cloud providers and data storage systems. It supports ultra-fast data transfers between data storage arrays and servers, ensuring high-speed data retrieval and backups for cloud-based services, big data analytics, and enterprise applications.
Long-Distance 5G Transport Networks
This module is optimized for 5G transport networks, providing long-distance, high-capacity links between 5G base stations and core networks. It ensures minimal latency and high throughput, making it ideal for supporting the ultra-reliable, low-latency communication required for 5G backhaul and fronthaul networks.
Rigorous Industrial Product Testing
ESOPTIC is equipped with a comprehensive range of professional testing equipment designed to assess various parameters of optical products.
This ensures the highest performance, quality, and stability of optical transmission in all of our products.
Product packaging specification
Packing of module products
Put the qualified products into the corresponding model blister box packaging.
The bottom, surface and side of the carton are filled with one piece of anti-static foam to protect the product.According to the requirements of the packing quantity, put the blister box box of the product into the packaging carton. If the space between the blister boxes is large, use a piece of anti-static foam to put it in the middle. The empty space in the end box must be filled with anti-static foam to ensure that it will not be damaged during transportation.
The outer case label is attached to the side position of the outer case,Label the outer case after sealing.
At the time of delivery, the entire outer box should be wrapped with at least 2 layers of wrapping film protection.
