| Part Number | ESANLL31-K10C | Distance | 2km |
| Form Factor | QSFP+ | Connector | LC duplex |
| Wavelength | 1310nm | Transmitter | DFB |
| Receiver | PIN | Media | Single-Mode Fiber?(SMF) |
| Power Consumption | <3.5W | Protocol | 40G Base Ethernet |
| Case Temperature(℃) | C: 0℃ to +70℃ / I: -40℃ to +85℃ |
Product Features
Supports 41.2 Gb/s aggregate bit rates
Uncooled 4x10Gb/s CWDM Transmitter
Maximum link length of 150m on OM3, 160m on OM4,and 2km on Single Mode Fiber (SMF)
Hot-pluggable QSFP+ footprint
Duplex LC receptacles
Power dissipation <3.5W
Compliant to the SFF-8636 Common Management Interface MSA
Single 3.3V power supply
Support Digital Diagnostic Monitor interface
Product Highlights
Introducing our state-of-the-art 40G QSFP+ LR4 1310nm 02km optical module, the ultimate solution for high-speed, long-distance data transmission. Leveraging cutting-edge QSFP 40G LR4 technology, this module supports 40GBASE LR4 standards, ensuring seamless integration into your existing network infrastructure. Unlike traditional 40G SFP modules, the QSFP+ 40G LR4 offers extended reach up to 2 kilometers over single-mode fiber, making it ideal for backbone and metro network applications. With its robust performance and reliability, the 40G LR4 optical module is the perfect choice for upgrading your network to handle increasing data demands.
Long-Distance Ethernet Connectivity
The 40G QSFP+ LR4 1310nm module supports long-distance Ethernet connectivity, ideal for connecting high-speed Ethernet networks across metropolitan areas, enterprise campuses, or different cities. It enables reliable, high-performance communication for applications such as enterprise resource planning (ERP), customer relationship management (CRM), and unified communications.
Video Conferencing and Collaboration Networks
The 40G QSFP+ LR4 optical module is well-suited for video conferencing and collaboration networks, providing long-distance, high-bandwidth connections for HD and 4K video streaming. It supports reliable, low-latency communication between video conferencing systems, corporate headquarters, and remote offices, ensuring high-quality video calls and collaboration in global teams.
Rigorous Industrial Product Testing
ESOPTIC is equipped with a comprehensive range of professional testing equipment designed to assess various parameters of optical products.
This ensures the highest performance, quality, and stability of optical transmission in all of our products.
Product packaging specification
Packing of module products
Put the qualified products into the corresponding model blister box packaging.
The bottom, surface and side of the carton are filled with one piece of anti-static foam to protect the product.According to the requirements of the packing quantity, put the blister box box of the product into the packaging carton. If the space between the blister boxes is large, use a piece of anti-static foam to put it in the middle. The empty space in the end box must be filled with anti-static foam to ensure that it will not be damaged during transportation.
The outer case label is attached to the side position of the outer case,Label the outer case after sealing.
At the time of delivery, the entire outer box should be wrapped with at least 2 layers of wrapping film protection.
