| Part Number | ESWSMM85-S10C | Distance | 100m |
| Form Factor | QSFP-DD | Connector | MPO-12(APC) |
| Wavelength | 850nm | Transmitter | VCSEL |
| Receiver | PIN | Media | Multi-Mode Fiber(MMF) |
| Power Consumption | <8W | Protocol | 400G Base Ethernet |
| Case Temperature(℃) | C: 0℃ to +70℃ |
Product Features
Data rate: 400Gbps with PAM4 encoding
Data Rate: Up to 425Gbps (4xPAM453.125Gbps)
High-speed Interface: 400GAUI-8 electrical interface
Applications:
400GBASE-SR4
200GBASE-SR4
100GBASE-SR4
2x200GBASE-SR2
4x100GBASE-SR1
Compliant with QSFP-DD MSA standards
Optical Components: 4x VCSEL arrays, 4x PIN PD arrays
Management Interface: CMIS 5.0
Power Supply: +3.3V single supply
Product Highlights
Unleash the full potential of your network with our state-of-the-art 400G QSFP-DD SR4 850nm 100m module. This 400G Module is designed to meet the increasing demands for high-speed, high-density data transmission in modern data centers and cloud infrastructures. Leveraging the QSFP-DD SR4 form factor and PAM4 modulation technology, our 850nm Transceiver offers unparalleled bandwidth and reach over multi-mode fiber (MMF) at a distance of 100 meters.
Compliant with the QSFP-DD MSA (Multi-Source Agreement), our PAM4 Optical Transceiver ensures seamless integration and interoperability with a wide range of network equipment. Experience unmatched performance, reliability, and scalability with the 400G QSFP-DD SR4 850nm 100m module, designed to power the future of high-speed networking.
Content delivery networks
The 400G QSFPDD SR8 850nm 100m module supports the high-bandwidth demands of video streaming and content delivery networks (CDNs). It enables the fast and reliable transmission of high-definition and 4K/8K video content across data centers, ensuring smooth video playback and enhanced user experience.
5G Networks and Edge Computing
The 400G QSFP-DD SR4 is designed for 5G networks and edge computing, providing high-speed, low-latency connections between edge data centers, base stations, and core networks. This module ensures the fast transmission of data generated by IoT devices, enabling real-time processing for autonomous systems, smart cities, and mobile applications.
Rigorous Industrial Product Testing
ESOPTIC is equipped with a comprehensive range of professional testing equipment designed to assess various parameters of optical products.
This ensures the highest performance, quality, and stability of optical transmission in all of our products.
Product packaging specification
Packing of module products
Put the qualified products into the corresponding model blister box packaging.
The bottom, surface and side of the carton are filled with one piece of anti-static foam to protect the product.According to the requirements of the packing quantity, put the blister box box of the product into the packaging carton. If the space between the blister boxes is large, use a piece of anti-static foam to put it in the middle. The empty space in the end box must be filled with anti-static foam to ensure that it will not be damaged during transportation.
The outer case label is attached to the side position of the outer case,Label the outer case after sealing.
At the time of delivery, the entire outer box should be wrapped with at least 2 layers of wrapping film protection.
