| Part Number | ESHKLB45-K80C/ESHKLB54-K80C | Distance | 80km |
| Form Factor | SFP+ | Connector | sole LC |
| Wavelength | Tx1490/Rx1550nm/Tx1550/Rx1490nm | Transmitter | EML |
| Receiver | PIN | Media | Single-Mode Fiber?(SMF) |
| Power Consumption | <1.2W | Protocol | 10G Base Ethernet |
| Case Temperature(℃) | C: 0℃ to +70℃ / I: -40℃ to +85℃ |
Product Features
Up to 10.3125Gbps Data Links
1490nm /1550 Cooled EML laser transmitter and APD/TIA receiver
Maximum link length of 80km on 9/125um SMF
Hot-pluggable SFP+ footprint
LC receptacles
Low power dissipation＜2W
RoHS compliant and lead-free
Support Digital Diagnostic Monitor interface
Single +3.3V power supply
Compliant with SFF-8472
Case operating temperature
Product Highlights
Unlock the full potential of your network with our 10G SFP+ Bidi 80km Fiber Transceiver. This cutting-edge 10G Bidi solution offers unparalleled reach, extending your network's capabilities to an impressive 80 kilometers. Engineered with advanced bidirectional technology, our 10G Bidi 80km module not only doubles data throughput efficiency but also reduces the need for additional fiber strands, simplifying network infrastructure. Perfect for high-density deployments, the SFP 10GB transceiver seamlessly integrates into existing network equipment, ensuring seamless upgrades to 10 Gigabit speeds. Experience the future of networking with the reliability and efficiency of our 10GB SFP Fiber Transceiver, designed to maximize your network's performance and scalability.
Long-Distance Fiber Optic Communication
The 10G SFP+ Bidi 80km LC optical module is designed for long-distance fiber optic communication, enabling data transmission over distances up to 80 kilometers. Ideal for telecom operators and large enterprises, this module ensures high-speed, reliable data transfer between remote locations or regional offices. It is commonly used in backbone networks to extend the reach of existing fiber infrastructure with minimal cost by utilizing bidirectional transmission over a single fiber strand.
Telecom Backhaul Networks
The 10G SFP+ Bidi 80km LC module is a key component in telecom backhaul networks, where high-capacity data transmission is essential for linking base stations, remote nodes, and regional hubs to central offices or data centers. By offering long-distance transmission over a single fiber, this module helps reduce fiber costs while increasing network capacity. It is widely deployed in 4G/5G backhaul and is an essential part of modern wireless communication infrastructure.
Rigorous Industrial Product Testing
ESOPTIC is equipped with a comprehensive range of professional testing equipment designed to assess various parameters of optical products.
This ensures the highest performance, quality, and stability of optical transmission in all of our products.
Product packaging specification
Packing of module products
Put the qualified products into the corresponding model blister box packaging.
The bottom, surface and side of the carton are filled with one piece of anti-static foam to protect the product.According to the requirements of the packing quantity, put the blister box box of the product into the packaging carton. If the space between the blister boxes is large, use a piece of anti-static foam to put it in the middle. The empty space in the end box must be filled with anti-static foam to ensure that it will not be damaged during transportation.
The outer case label is attached to the side position of the outer case,Label the outer case after sealing.
At the time of delivery, the entire outer box should be wrapped with at least 2 layers of wrapping film protection.
