| Part Number | ESHKLB23-K10I/ESHKLB32-K10I | Distance | 20km |
| Form Factor | SFP+ | Connector | sole LC |
| Wavelength | 1270/1310nm | Transmitter | DFB |
| Receiver | PIN | Media | Single-Mode Fiber?(SMF) |
| Power Consumption | <1W | Protocol | 10G Base Ethernet |
| Case Temperature(℃) | C: 0℃ to +70℃ / I: -40℃ to +85℃ |
Product Features
Up to 10.3125Gbps Data Links
1270nm DFB /1330 DFB laser transmitter and PIN/TIA receiver
Maximum link length of 20km on 9/125um SMF
Hot-pluggable SFP+ footprint
LC receptacles
Low power dissipation
RoHS compliant and lead-free
Support Digital Diagnostic Monitor interface
Single +3.3V power supply
Compliant with SFF-8472
Product Highlights
Discover the ultimate in high-speed, long-distance connectivity with our 10G SFP+ Bidi 20km solution. This state-of-the-art Bidi SFP+ transceiver not only supports blazing-fast 10GB data rates but also ensures reliable transmission over an impressive 20 kilometers. Engineered for excellence, our 10G Bidi 20km module leverages advanced bidirectional technology to maximize efficiency and minimize costs. Whether you're upgrading your network infrastructure or deploying new systems, this SFP transceiver is the perfect choice for seamless, high-capacity data flow. Experience the future of networking with 10G SFP+ Bidi – where speed, distance, and reliability converge.
Smart Grid Infrastructure
The 10G SFP+ Bidi 20km module is a key component in smart grid infrastructure, enabling communication between remote monitoring stations, substations, and central control hubs. This ensures real-time monitoring of electricity usage, grid performance, and fault detection, contributing to efficient energy distribution and system optimization. Its bidirectional capabilities allow for efficient data exchange over long distances, enhancing the scalability and reliability of the smart grid system.
Multi-Tenant Building Connectivity
The 10G SFP+ Bidi 20km module is perfect for connecting multiple tenants in a multi-tenant building. It enables reliable, high-speed data transmission between different floors or buildings within the same complex, supporting a range of applications such as tenant-to-tenant communication, high-speed internet access, and video surveillance systems. Its bidirectional nature reduces the number of fibers needed, making it an ideal choice for providing scalable, cost-effective solutions for multi-tenant environments.
Rigorous Industrial Product Testing
ESOPTIC is equipped with a comprehensive range of professional testing equipment designed to assess various parameters of optical products.
This ensures the highest performance, quality, and stability of optical transmission in all of our products.
Product packaging specification
Packing of module products
Put the qualified products into the corresponding model blister box packaging.
The bottom, surface and side of the carton are filled with one piece of anti-static foam to protect the product.According to the requirements of the packing quantity, put the blister box box of the product into the packaging carton. If the space between the blister boxes is large, use a piece of anti-static foam to put it in the middle. The empty space in the end box must be filled with anti-static foam to ensure that it will not be damaged during transportation.
The outer case label is attached to the side position of the outer case,Label the outer case after sealing.
At the time of delivery, the entire outer box should be wrapped with at least 2 layers of wrapping film protection.
