| Part Number | ESHKLB31-K40I | Distance | 40km |
| Form Factor | SFP+ | Connector | LC duplex |
| Wavelength | 1310nm | Transmitter | DFB |
| Receiver | APD | Media | Single-Mode Fiber?(SMF) |
| Power Consumption | <1.2W | Protocol | 10G Base Ethernet |
| Case Temperature(℃) | C: 0℃ to +70℃ / I: -40℃ to +85℃ |
Product Features
Up to 11.3Gbps Data Links
Cooled 1550nm EML laser transmitter and PIN/TIA receiver
Maximum link length of 40km on 9/125um SMF
Hot-pluggable SFP footprint
Duplex LC receptacles
Low power dissipation
RoHS compliant and lead-free
Support Digital Diagnostic Monitor interface
Single +3.3V power supply
Compliant with SFF-8472
Product Highlights
Experience unparalleled performance with our 10G SFP+ ER 1310nm 40km LC fiber optic transceiver module. As a premium SFP+ solution, it leverages advanced technology to deliver robust, high-speed data transmission over single-mode fiber, making it ideal for long-haul networks. Our 10G SFP+ ER module ensures seamless integration into your existing infrastructure, offering exceptional reach of up to 40 kilometers. Whether you're upgrading your network or building a new one, trust our Single Mode SFP for reliable, high-capacity connectivity. Choose our SFP 10G ER and elevate your network's performance to the next level.
Public and Private Network Integration
The 10G SFP+ ER 1310nm 40km LC module is ideal for integrating public and private networks, allowing businesses to extend their internal network infrastructure over large distances. It can be used to link private corporate networks with public internet infrastructure, providing secure and high-speed data transmission across metropolitan and regional networks. This optical module helps organizations efficiently manage their hybrid network environments and ensure reliable data transfer between public and private domains.
Hybrid Cloud Networking
The 10G SFP+ ER 1310nm 40km LC module plays a critical role in hybrid cloud networking by providing long-distance, high-speed connectivity between private and public cloud infrastructure. It enables secure and seamless communication between on-premise data centers and cloud platforms, allowing businesses to optimize their data storage, backup, and computing resources. This optical module is ideal for organizations looking to integrate their internal network with cloud services, ensuring high performance and reliability over extended distances.
Rigorous Industrial Product Testing
ESOPTIC is equipped with a comprehensive range of professional testing equipment designed to assess various parameters of optical products.
This ensures the highest performance, quality, and stability of optical transmission in all of our products.
Product packaging specification
Packing of module products
Put the qualified products into the corresponding model blister box packaging.
The bottom, surface and side of the carton are filled with one piece of anti-static foam to protect the product.According to the requirements of the packing quantity, put the blister box box of the product into the packaging carton. If the space between the blister boxes is large, use a piece of anti-static foam to put it in the middle. The empty space in the end box must be filled with anti-static foam to ensure that it will not be damaged during transportation.
The outer case label is attached to the side position of the outer case,Label the outer case after sealing.
At the time of delivery, the entire outer box should be wrapped with at least 2 layers of wrapping film protection.
